BM06K LENS

About BM06K LENS

The Raytools BM06K Auto Focus Laser Cutting Head is a medium- to high-power fiber laser cutting head designed for industrial laser cutting machines. It supports laser power up to about 6 kW and includes an automatic focus adjustment system that improves cutting precision, speed, and stability when processing metals.

Basic Description

The BM06K cutting head receives the laser beam from a fiber laser source and focuses it into a small spot to cut metal sheets or tubes. It contains optical components such as collimating lenses, focusing lenses, protective lenses, and a nozzle system for assist gas during cutting.

Key Features

• Auto-focus technology automatically adjusts the focal point for different material thickness.

• Power capacity up to 6 kW for medium and high-power fiber laser machines.

• Efficient cooling system for collimation and focusing modules plus nozzle cooling airflow.

• Four protective lenses to reduce contamination and extend optical component life.

• Real-time temperature monitoring of the protective lens with alarm protection.

• Multiple fiber interfaces (QBH / QD / G5) compatible with many laser sources.

Main Technical Specifications

• Model: BM06K

• Laser Power: 6 kW

• Fiber Interface: QBH / QD / G5

• Collimation Focal Length: 100 mm (F100)

• Focus Lens Options: F150 / F200

• Auto-focus Range: approx. 17 mm to 32 mm (depending on lens)

• Assist Gas Pressure: up to 2530 bar

• Weight: about 7 kg

• Wavelength: 1080 nm (fiber laser)
